Kioti – RX7320, 7320C, 7320P, 7320PC, 7320PCCR

Eco-Friendly Diesel Engine – The New Common Rail Diesel Engine (CRDI) improves fuel efficiency over 20% while reducing noise levels. With this Eco-friendly Tier 4 Engine, the RX Series offers the operator a quiet work environment with powerful performance.

Categories: , Tags: , ,

Engine Model: 4F243T
Engine Type: 4 Cyl. In-line Vertical, Water-cooled 4-cyle Turbo Diesel, CRDI
Engine Gross: 73 HP
Engine PTO: 63 HP
Displacement: 148.6 cu. in.
Rated Revolution: 2600 rpm
Fuel Tank Capacity: 22.5 gal. / 25.0 gal.
Clutch: Dry Single Plate / Wet Disc
Transmission: Synchro Shuttle / Power Shuttle / Power Shuttle with Creeper
Speeds: 12F x 12R / 24F x 24R
Differential Lock: Rear Standard
Brake: Wet Multi Disc
Drive Train PTO: Independent
Rear PTO: Standard – 540 / 540E
Mid PTO: N/A
4WD Type: Hydraulic
Pump: Gear
Pump Capacity: 19.2 gpm
3 Pt. Hitch: Category II
Max Lifting Capacity: 3,898 lbs.
Hydraulic Lift Control: Position, Draft, Mixed Control
Number of Standard Remote Valves: 1st: Std. 2nd, 3rd: Opt.
Steering: Hydrostatic Power Steering
Tire Size Front AG: 11.2-24
Tire Size Rear AG: 16.9-30
Speed Forward: 1.01-23.53 mph / 0.11-23.53 mph
Speed Reverse: 1.00-23.13 mpg / 0.11-23.13 mph
Overall Length: 146.3 in.
Overall Width: 77.2 in.
Overall Height: 107.5 in. / 104.5 in.
Wheelbase: 83.9 in.
Minimum Ground Clearance: 17.3 in.
Front Tread: 58.1 in.
Rear Tread: 59.6 in.
Minimum Turning Radius: 11.2 feet
Weight with Cab and AG Tires: 5,589 lbs. / 6162 lbs. / 5600 lbs / 6162 lbs.
