Kioti – Disc Harrows

Kioti Low Horsepower, Standard-Duty and Medium-Duty Disc Harrows

Model: DH1548
Product Description: Low Horsepower 48″ Disc Harrow
Blade Length (in.): 16 Notched Blades
Tractor Engine Range (hp): up to 35
Tractor Hitch: Category 1, Ltd Category 1, Category 0 Optional
Width (in.): 48
Average Weight (lb.): 390
Disc Blade Type: Notched
Average Weight per Blade (lb.): 33
Disc Diameter (in.)/ Quantity: 16/12
Disc Spacing: 7.5 Front and Rear
Gang Axle Diameter (in.): 1 Square
Frame Construction: 3 X 3 Tube and Angle
Quick Hitch Compatible: Yes

Model: DH2064
Product Description: Standard-Duty 64″ Disc Harrow
Blade Length (in.): 18 Combo Blades
Tractor Engine Range (hp): 25-45
Tractor Hitch: Category 1
Width (in.): 64
Average Weight (lb.): 508
Disc Blade Type: Combination Smooth and Notched
Average Weight per Blade (lb.): 36
Disc Diameter (in.)/ Quantity: 18/14
Disc Spacing: 9 Front, 7.5 Rear
Gang Axle Diameter (in.): 1 Square
Frame Construction: 3 X 3 Tube and Angle
Quick Hitch Compatible: Yes

Model: DH2080
Product Description: Standard-Duty 80″ Disc Harrow
Blade Length (in.): 18 Combo Blades
Tractor Engine Range (hp): 35-55
Tractor Hitch: Category 1
Width (in.): 80
Average Weight (lb.): 590
Disc Blade Type: Combination Smooth and Notched
Average Weight per Blade (lb.): 33
Disc Diameter (in.)/ Quantity: 18/18
Disc Spacing: 9 Front, 7.5 Rear
Gang Axle Diameter (in.): 1 Square
Frame Construction: 3 X 3 Tube and Channel
Quick Hitch Compatible: Yes

Model: DH3080
Product Description: Medium-Duty 80″ Disc Harrow
Blade Length (in.): 20 Combo Blades
Tractor Engine Range (hp): 45-75
Tractor Hitch: Category 1 & 2
Width (in.): 80
Average Weight (lb.): 845
Disc Blade Type: Combination Smooth and Notched
Average Weight per Blade (lb.): 47
Disc Diameter (in.)/ Quantity: 20/18
Disc Spacing: 9 Front, 7.5 Rear
Gang Axle Diameter (in.): 1 1/8 Square
Frame Construction: 3 X 3 Tube
Quick Hitch Compatible: Yes

Model: DH3096
Product Description: Medium-Duty 96″ Disc Harrow
Blade Length (in.): 20 Combo Blades
Tractor Engine Range (hp): 55-85
Tractor Hitch: Category 1 & 2
Width (in.): 96
Average Weight (lb.): 960
Disc Blade Type: Combination Smooth and Notched
Average Weight per Blade (lb.): 44
Disc Diameter (in.)/ Quantity: 20/22
Disc Spacing: 9 Front, 7.5 Rear
Gang Axle Diameter (in.): 1 1/8 Square
Frame Construction: 3 X 3 Tube
Quick Hitch Compatible: Yes
