Kioti – DK4710SE HC

Hire
  • / Day

Diesel engine with Daedong ECO Technology

The 44.9 hp (33.5 kW) Common Rail Diesel Engine (CRDI) improves fuel efficiency while reducing noise levels. With this Eco-friendly Tier 4 engine, the DK10SE Series offers the operator a quiet work environment with powerful performance.

Power Steering

The standard power steering minimizes the effort required to make tight, repetitive turns.

Categories: , Tags: , ,

Engine Model: 3F-THL4-U
3-Point Hitch Standard Category (Optional Category): Category 1
Lift Capacity, 24 inch aft of hitch, lb(kg): 2,683 lbs. (1,217 kg)
Control Type: Position
Total Pump Flow: 16.49 gpm (62.4 L/min)
Turning Radius with Brake: 8.63 ft. (2.6 m)
Rear Tread Ag Tires – Min: 49.2 in. (1,251 mm)
Front Tread Ag Tires – Min: 49.2 in. (1,252 mm)
Ground Clearance: 14.5 in. (368 mm)
Wheelbase: 71.3 in. (1,810 mm)
Height from Top of Cab: 93 in. (2,363 mm)
Width: 62.8 in. (1,596 mm)
Length with 3-point hitch: 125.5 in. (3,189 mm)
Clutch: None
Brakes: Wet Disc Type
Mid PTO Speeds: 2,000 rpm (Optional)
Rear PTO Speeds(1st): 540 rpm
PTO Power: 33.4 hp (24.9 kW)
PTO Type Trans: Independent
Max. Travel Speed of Forward with Ag1 @ Engine rated speed: 18.5 mph (29.7 km/h)
Min. Travel Speed of Forward with Ag1 @ Engine rated speed: 0 mph (0 km/h)
No. of Travel Speed Forward / Reverse: 3 Range
Transmission Type: Hydrostatic
Fuel Tank Capacity: 12.7 gal. (48 L)
Displacement: 111.4 cu. in. (1,826 cc)
Fuel Type: Diesel
No. of Cylinder: 3
Rated Speed: 2,600 rpm
Engine Gross Power: 44.9 hp (33.5 kW)
Weight with Ag Tires with Cab: 4,043.3 lbs. (1,834 kg)

Additional information

Additional Features

Deluxe Suspension Seat

The ergonomically designed, adjustable suspension seat allows the operator to ride in comfort.

Dual HST Pedal

DK10SE models utilize a two pedal system for forward and reverse with smooth engagement, acceleration and deceleration. Dual pedals provide easier use which reduces operator fatigue during long hours of work and when doing repetitive tasks.

Simple Maintenance

KIOTI tractors are designed for easy maintenance. Lift able hoods allow convenient access for daily service checks. Maintaining your tractor for long life and high performance has never been easier.

Air Conditioning System

DK10SE cab models come standard with a cooling and heating system ensuring comfortable working conditions all year round.
