Kioti – Snow Blower SB50, SB54, SB54A, SB66, SB72

Hire
  • / Day

Front Mount Snow Blowers

Clear the way with KIOTI front mount snow blowers. They quickly hitch to the sub-frame for easy mounting and operate on a mid-mount PTO drive, offering plenty of snow blasting power. All units come with a 12-month warranty.

Specifications and design are subject to change without notification.

Model: SB50
Product Description: 50″ Snow Blower
KIOTI recommended units: CS2410
Recommended PTO: 15-20 hp
Cutting Width: 50″
Cutting Height: 20″
Lift Height: +8”, -4”
Fan RPM: 1050
Fan Diameter: 16″
Fan Shaft Diameter: 1″
Fan Depth: 5 1/2″
Fan Center Height: 9 1/2″
Balanced Fan: Standard
Number Of Blades: 4
Main Auger Diameter: 12 3/4″
Balanced Auger: Standard
Hydraulic Chute Rotation On Polyethylene: Standard
Discharge Chute Angle: 282º
Manual Chute Deflector: Standard
Hydraulic Chute Deflector: N/A
Electric Chute Deflector: N/A
Chute 1 Deflector: Standard
Chute 2 Deflector: N/A
Removable and Replaceable Cutting Edge: N/A
Fixed Cutting Edge: .250” x 1.5” Standard
Lateral Skid Shoes: Adjustable Optional
PTO Shaft Number: 6E drive shaft
Driving Chain Number: 40
Number Of Safety Bolts: 3
Special hitch attach & drive kit for KIOTI: Standard
Length: 25 1/2″
Width: 50”
Height: 44”
Weight (lb): 286

Model: SB54A
Product Description: 54″ Snow Blower
KIOTI recommended units: CK2510
Recommended PTO: 15-20 hp
Cutting Width: 54″
Cutting Height: 22 1/2”
Lift Height: +10”, -6”
Fan RPM: 850
Fan Diameter: 18’’
Fan Shaft Diameter: 1 1/4″
Fan Depth: 6’’
Fan Center Height: 12 1/4″
Balanced Fan: Standard
Number Of Blades: 4
Main Auger Diameter: 14’’
Balanced Auger: Standard
Hydraulic Chute Rotation On Polyethylene: Standard
Discharge Chute Angle: 282º
Manual Chute Deflector: Standard
Hydraulic Chute Deflector: Optional
Electric Chute Deflector: Optional
Chute 1 Deflector: Standard
Chute 2 Deflector: Optional
Removable and Replaceable Cutting Edge: N/A
Fixed Cutting Edge: .375” x 1” Standard
Lateral Skid Shoes: Fixed Standard/ Adjustable Optional
PTO Shaft Number: 6E drive shaft
Driving Chain Number: 50
Number Of Safety Bolts: 2
Special hitch attach & drive kit for KIOTI: Standard
Length: 33”
Width: 54”
Height: 48 3/4”
Weight (lb): 675

Model: SB66
Product Description: 66″ Snow Blower
KIOTI recommended units: CK27, CK30, CK35, CK3510, CK3510H, CK4010, CK4010H
Recommended PTO: 20-40 hp
Cutting Width: 66″
Cutting Height: 25”
Lift Height: +11”, -5”
Fan RPM: 702
Fan Diameter: 22’’
Fan Shaft Diameter: 1 1/4″
Fan Depth: 7’’
Fan Center Height: 14″
Balanced Fan: Standard
Number Of Blades: 4
Main Auger Diameter: 15’’
Balanced Auger: Standard
Hydraulic Chute Rotation On Polyethylene: Standard
Discharge Chute Angle: 282º
Manual Chute Deflector: Standard
Hydraulic Chute Deflector: Optional
Electric Chute Deflector: Optional
Chute 1 Deflector: Standard
Chute 2 Deflector: Optional
Removable and Replaceable Cutting Edge: Reversible blade .375” x 2” Standard
Fixed Cutting Edge: N/A
Lateral Skid Shoes: Adjustable
PTO Shaft Number: 6E drive shaft
Driving Chain Number: 50
Number Of Safety Bolts: 2
Special hitch attach & drive kit for KIOTI: Standard
Length: 38”
Width: 66”
Height: 55”
Weight (lb): 842

Model: SB72
Product Description: 72″ Snow Blower
KIOTI recommended units: DKSE & NX Series
Recommended PTO: 25-40 hp
Cutting Width: 72’’
Cutting Height: 27 1/2”
Lift Height: +11”, -5”
Fan RPM: 719
Fan Diameter: 24’’
Fan Shaft Diameter: 1 1/4″
Fan Depth: 37 1/2’’
Fan Center Height: 15″
Balanced Fan: Standard
Number Of Blades: 4
Main Auger Diameter: 15’’
Balanced Auger: Standard
Hydraulic Chute Rotation On Polyethylene: Standard
Discharge Chute Angle: 282º
Manual Chute Deflector: Standard
Hydraulic Chute Deflector: Optional
Electric Chute Deflector: Optional
Chute 1 Deflector: Standard
Chute 2 Deflector: Optional
Removable and Replaceable Cutting Edge: Reversible blade .375” x 2” Standard
Fixed Cutting Edge: N/A
Lateral Skid Shoes: Adjustable
PTO Shaft Number: 6E drive shaft
Driving Chain Number: 50
Number Of Safety Bolts: 2
Special hitch attach & drive kit for KIOTI: Standard
Length: 39”
Width: 72”
Height: 57”
Weight (lb): 1108

Model: SB54
Product Description: 54″ Snow Blower
KIOTI recommended units: CK20S
Recommended PTO: 15-20 hp
Cutting Width: 54″
Cutting Height: 22 1/2”
Lift Height: +10”, -6”
Fan RPM: 850
Fan Diameter: 18’’
Fan Shaft Diameter: 1 1/4″
Fan Depth: 6’’
Fan Center Height: 12 1/4″
Balanced Fan: Standard
Number Of Blades: 4
Main Auger Diameter: 14’’
Balanced Auger: Standard
Hydraulic Chute Rotation On Polyethylene: Standard
Discharge Chute Angle: 282º
Manual Chute Deflector: Standard
Hydraulic Chute Deflector: Optional
Electric Chute Deflector: Optional
Chute 1 Deflector: Standard
Chute 2 Deflector: Optional
Removable and Replaceable Cutting Edge: N/A
Fixed Cutting Edge: .375” x 1” Standard
Lateral Skid Shoes: Fixed Standard/ Adjustable Optional
PTO Shaft Number: 6E drive shaft
Driving Chain Number: 50
Number Of Safety Bolts: 2
Special hitch attach & drive kit for KIOTI: Standard
Length: 33”
Width: 54”
Height: 48 3/4”
Weight (lb): 675
