ENGINE
Engine Model: 3TNV88F
Engine Manufacturer: Yanmar
Engine Power: 24.50 hp (18.30 kW)
Engine Displacement: 100.20 cu. in. (1,642 cc)
RPM:
Fuel Type: Diesel
Aspiration: Naturally Aspirated
Fuel Capacity: 14.50 gal (55 L)
Oil Capacity: 1.80 gal (6.70 L)
Coolant Capacity: 1.90 gal (7 L)
Radiator Coolant Capacity: 1.50 gal (2.90 L)
HYDRAULICS
Hydraulic Reservoir: 11.10 gal (42 L)
Rated Lift Capacity (Over Blade 10′ Reach): 2,315 lb (1,050 kg)
Rated Lift Capacity (Over Side 10′ Reach): 1,798 lb (815 kg)
OPERATING SPECS
Main Pump Type: Open Center
Maximum Flow & Pressure: 26.2 gpm / 2611 psi (99 lpm / 180 bar)
Auxiliary Hydraulic Flow (AUX 1 / AUX 2): 15.6 gpm / 7.9 gpm (60 lpm / 30 lpm)
Auxiliary Hydraulic Pressure (AUX 1 / AUX 2): 1435 psi / 972 psi (99 bar / 67 bar)
Swing Speed: 10 rpm
Boom Swing Angle: 99 ° / 66 °
DIMENSIONS
Length: 15.90 in (4,810 mm)
Width: 5.70 in (1,700 mm)
Height: 8.20 in (2,500 mm)
Ground Clearance: 10 in (258 mm)
Crawler / Track Length: 6.10 in (2,100 mm)
Shoe Width: 12 in (300 mm)
Weight: 8,510 lb (3,860 kg)
