Weight w/ Ag Tires w/ Cab: 10,230 lbs.
Control Type: Electronic
Lift Capacity 3pt Hitch lb(kg): 8,002 lbs.
3-Point Hitch Standard Category (Optional Category): Category #2
Main Pump Capacity: 32 gpm
Pump Type: Gear
Turning Radius: 12.69 ft.
Rear Tread: 70.47 in.
Front Tread: 65.35 in.
Ground Clearance: 18.94 in (Min.)
Wheelbase: 94.88 in
Height from Top of Cab: 111.93 in
Width: 88.58 in.
Length w/ 3-point hitch: 170.78 in.
Clutch: Wet Multi Disc
Brakes: Wet Multi Disc
Fuel Type: Diesel w/ Def system
Transmission Type: Manual – Power Shuttle
PTO Type: Independent
PTO Control Type: Electronic
Engine Model: 4J243TA-TP5B
Engine Gross Power: 115.30 HP
Rated Speed: 2,200 rpm
Aspiration: Intercular
Displacement: 233.90 cu. in. (3,833 cc)
Fuel Tank Capacity: 47.60 gal. (180L)
No. of Travel Speed Forward / Reverse: 24F/24R
Min. Travel Speed of Forward: 1.15 mph
Max. Travel Speed of Forward: 23.84 mph
- Min. Travel Speed of Reverse: 1.14 mph
Max. Travel Speed of Reverse: 23.67 mph
PTO Power: 83.90 HP
Rear PTO Speeds: 540 rpm / 540E / 1000
