Engine
Type: Kohler Confidant
Engine Gross hp (kW): 21 (15.65)
Displacement cu. in. (cc): 44.24 (725)
Choke: Manual
Fuel Tank Capacity gal. (l ): 7.5 (28.39)
Fuel Requirement: Unleaded Gasoline (87 Octane or higher)
Drive Train
Model: Hydro-Gear ZT-3200
Displacement (Pump/Motor) cc: 10/16
PTO Type
Clutch ft./lb.: 125
Electrical
Charging System amp: 15
Tire Size
Front: 13 x 5-6
Rear: 23 x 9.5-12
Traveling Speeds
Forward mph (km/h): 9 (14.48)
Parking Brake: Internal Integrated in Axle
Dimensions
Overall Length in. (mm): 80.7 (2,049.78)
Overall Width in. (mm): 60.7 (1,541.78)
Overall Height in. (mm): 71.5 (1,816.1)
Wheelbase in. (mm): 48.5 (1,231.9)
Width (Tire to Tire) in. (mm): 50.3 (1,277.62)
Approximate Curb Weight lb. (kg): 970 (439.98)
Mower Deck
Mower Deck Type: Fabricated
Lift Mechanism: Foot Pedal
Deck Steel Thickness: 10-gauge with 7-gauge at edge area
Anti-Scalp Ball Rollers: 5 (4 front, 1 rear)
Cutting Width of Mower in. (mm): 48 (1,219.2)
Blades: Notched (Opt. Serrated)
Cutting Height in. (mm): 1.5-5 (38.1-127)
Discharge Chute: Side (Molded Rubber)
Deck Height Adjustment: Dial Type
Seat
Suspension: Standard (1.5 Inch Suspension)
Sliding Adjustment: Standard
Arm Rest: Standard
Seat Belt: Standard
Standard/Optional
Foldable ROPS: Standard
Head Light: Standard
Power Socket: Standard
