Engine:
Model: 3HT-S4TM45A
Engine Manufacturer: KIOTI
Power: 44.90 hp (33.50 kW)
Displacement: 111.40 cu. in. (1,826 cc)
RPM: 2,600 rpm
Fuel Type: Diesel
Aspiration: Turbo Charged
Fuel Capacity: 13.20 gal (50 L)
Transmission:
Transmission: Hydrostatic
Shuttle: Hydrostatic
Travel Speeds Forward: 3
Travel Speeds Reverse: 3
Travel Speeds Minimum Speed: 17.50 mph (28.10 km/h)
Travel Speeds Maximum Speed: 17.50 mph (28.10 km/h)
Travel Speeds Min Reverse Speed: 12.20 mph (19.70 km/h)
Travel Speeds Max Reverse Speed: 12.20 mph (19.70 km/h)
PTO:
PTO Type: Independent
PTO Power: 36.60 hp (27.30 kW)
Rear Speed: 540
Mid Speed: 2,000 (optional)
Drive Train:
Brakes: Wet Multi Disc
Clutch: None
Steering: Hydrostatic Power Steering
Hydraulics:
Pump: Gear
Pump Capacity: 16.50 gpm (62.40 lpm)
Lift Capacity: 2,493 lb (1,131 kg)
Hitch:
Type: Three Point
Category: Category 1
Control Type: Position with Draft Control
Lift Capacity: 2,493 lb (1,131 kg)
Dimensions:
Length with Hitch: 136.40 in (3,465 mm)
Width: 67.10 in (1,705 mm)
Wheelbase Length: 75.50 in (1,918 mm)
Ground Clearance: 13.40 in (340 mm)
Front Tread: 51.10 in (1,297 mm)
Rear Tread: 54.30 in (1,380 mm)
Turning Radius: 11.04 ft (3.37 m)
Weight: 4,027 lb (1,827 kg)
Height: 98.40 in (2,500 mm)
